64 SECTION 25 - FRONT AXLES
Use an extractor to remove bearing (2).
Loosen all fastening screws (1) of the ring gear (11).
SWARNING
This operation makes both differential half boxes
free, so take care not to lower the inner compo-
nents.
Remove the ring gear (11) by means of a hammer.
Check the marking points (3) and (10) that will be
useful during the assemblage.
F27307
2
F27308
1
11
11
F27309
F27310
3
10
