SECTION 27 - REAR AXLE 33
Assembly
Remove the front flange (2).
Remove the seal ring (3), the O-ring (4), the gasket
(5), the O-ring (6) and the washer (7).
Assemble the washer (7) and the new O-ring (6).
Assemble the gasket (5).
F28012
2
F29009
4
3
5
6
7
F29322
6
7
F29323
5
