4 SECTION 21 - TRANSMISSION
END FLOAT
Input forward Primary Shaft ...................................................................................................... 0.0508-0.41 mm
Input reverse Primary Shaft ...................................................................................................... 0.0508-0.41 mm
Output shaft................................................................................................................ 1st Gear - 0.33-0.508 mm
..................................................................................................................................2nd Gear - 0.35-0.558 mm
...................................................................................................................................3rd Gear - 0.38-0.838 mm
...................................................................................................................................4th Gear - 0.20-0.558 mm
4WD Shaft................................................................................................................................... 0.050-0.28 mm
Bearing End Floats.................................................................................................................... 0.025-0.076 mm
Bearing End Float Shims available ................................................... 0.050/0.076/0.127/0.177/0.381/0.508 mm
HYDRAULIC TESTS
Tachometer setting .............................................................................................................................. 2000 rpm
Test temperature, oil ............................................................................................................................. 80-85 °C
Cold start valve (for reference only) .......................................................................................................... 26 bar
System pressure test .....................................................................................................................13.7-15.2 bar
Torque converter....................................................................................................................................7-11 bar
Reverse Clutch...............................................................................................................................13.7-15.2 bar
Forward Clutch...............................................................................................................................13.7-15.2 bar
4WD Supply ...................................................................................................................................13.7-15.2 bar
COOLER FLOW TEST
Oil temperature 80-85 °C ..................................................... Rpm ..................................................Oil flow l/min
...............................................................................................700 .......................................................12.5 litres
.............................................................................................1000 .......................................................18.2 litres
.............................................................................................1500 .......................................................22.1 litres
.............................................................................................2000 .......................................................24.0 litres
.............................................................................................2200 .......................................................24.5 litres
.............................................................................................2500 .......................................................25.0 litres
