2000-4
STEP 7
BD03A231
Double up a nylon lifting strap (1) and slide through
the exhaust stack (2) on the hood.
STEP 8
BD03A230
Place a solid steel bar through the strap, raise the
hood and release tension on the lifting motor.
STEP 9
BD03A228
Remove the pin from the top of the lifting motor.
STEP 10
BD06F109
Tag and disconnect hood wiring harness connector
from rear chassis wiring harness connector.
STEP 11
BD03A227
BD03A226
Remove mount bolt (1) and backup alarm wiring
harness clamp from cooler housing. Have another
person balance the hood and remove the hood hinge
mounting bolts (2) from the cooler frame.
To Next Page
