2000-5
STEP 12
BD03A232
Carefully raise and remove hood from loader. Lower
hood onto suitable platform and disconnect lifting
equipment.
STEP 13
BD03A224
Tag and disconnect engine wiring harness connector
from air filter restriction switch.
STEP 14
BD03A225
Loosen clamp on air cleaner intake hose and remove
the crankcase ventilation hose.
STEP 15
BD06F110
Loosen clamps on turbocharger and air cleaner,
remove the intake hose.
STEP 16
BD06F110
Loosen the clamp on the turbocharger for the after
cooler inlet hose.
STEP 17
BD03A115
Loosen the clamp on the after cooler and remove the
after cooler inlet hose from the machine.
