2000-7
STEP 23
BD06F115
Remove the drive belt from the engine.
STEP 24
BD06F116
Loosen clamps and remove lower cooler hose from
the engine.
STEP 25
BD06F117
If loader is equipped with air conditioning, identify,
tag, and disconnect the engine wiring harness
connectors from air compressor clutch connector (1).
Remove the three mounting bolts (2) for the
compressor and set the compressor on the left
battery cover.
STEP 26
BD06F118
Tag and disconnect the wiring from the alternator.
STEP 27
BD06F119
Remove bolt securing wiring harness clamp to
engine.
STEP 28
BD06F120
Remove bolt securing wiring harness clamp (1) to the
engine. Remove ground wires (2) from the engine.
To Next Page
