2000-9
STEP 35
BD06F124
Tag and disconnect the fuel filter heater wires (1),
disconnect the fuel line (2) from the fuel filter head,
plug the line and cap the fitting.
STEP 36
BD06F125
Remove bolt and clamp.
STEP 37
BD06F126
Connect and turn on vacuum pump to hydraulic
reservoir. Tag and remove the hydraulic lines from
the brake system pump, plug the lines and cap the
fittings.
STEP 38
BD06F127
Remove the lower cover for the drive shaft.
STEP 39
BD03A172
Remove the drive shaft bolts from the flywheel. Move
the drive shaft clear of the flywheel.
STEP 40
Connect suitable lifting equipment to engine lifting
brackets. Take up all slack in lifting equipment.
Remove the engine mounting bolts and lift the engine
enough to gain access to the drain hose, pull the
drain hose with the engine.
STEP 41
Slowly raise engine from rear chassis. Be sure all
harness connections and hoses have been
disconnected and are clear of the engine. Remove
engine from machine.
