4 - 40
DIAGNOSTIC - SELECTION
CASE TRAINING CENTER
AUGUST 2000
6
The hydraulic oil temperature is
not displayed or is below 25°C
on the CHK1 check screen
The electrical harness between
the hydraulic oil temperature
sender and the electronic control
box (CN1 terminal 6 and 13) is
defective
Repair the electrical harness
Voltage below 5 V, at sender
input
Change the electronic control
box
Voltage equal to 5 V, at sender
input
Change the oil temperature
sender
