Case CX130 - Page 136

4 - 48
DIAGNOSTIC - SELECTION
CASE TRAINING CENTER
AUGUST 2000
BS98F255
2. Connect the appropriate service connector (2P) to the connector on the speed detector only and install the meter.
3. When the connection has been made, the speed detector resistance should be 0.7 k9 at 25°C.
NOTE: The resistance value varies with temperature.
