Case CX130 - Page 45

COMPONENTS CX130
3 - 11
CASE TRAINING CENTER
AUGUST 2000
Neutral position
TO BOOM OR ARM SPOOL
SPOOLS E
FROM PILOT PRESSURE
TO RETURN FILTER
FROM HAND CONTROL
S PORT
FROM CONTROL VALVE RETURN
CUSHION
SHUT-OFF
SOLENOID VALVE
TO RETURN FILTER
SPOOL F
FROM HAND CONTROL
