Case CX210B - Complete Machine Dimensions

Issued 09-2014
1002-11
Complete machine dimensions
CX210B(STD type, standard boom)
Arm (dipper)
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Lenght (without attachment)
4810 mm
(189.37 in)
4810 mm
(189.37 in)
4810 mm
(189.37 in)
Lenght (with attachment)
9400 mm
(370.08 in)
9490 mm
(373.62 in)
9480 mm
(373.23 in)
Height (with attachment)
2970 mm
(116.93 in)
3090 mm
(121.65 in)
3190 mm
(125.59 in)
CX210B (LC type, standard boom)
Arm (dipper)
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Lenght (without attachment)
4955 mm
(195.08 in)
4955 mm
(195.08 in)
4955 mm
(195.08 in)
Lenght (with attachment)
9400 mm
(370.08 in)
9490 mm
(373.62 in)
9480 mm
(373.23 in)
Height (with attachment)
2970 mm
(116.93 in)
3090 mm
(121.65 in)
3190 mm
(125.59 in)
CX210B (LC type, articulated boom)
Arm (dipper)
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Lenght (without attachment)
4955 mm
(195.08 in)
4955 mm
(195.08 in)
4955 mm
(195.08 in)
Lenght (with attachment)
9400 mm
(370.08 in)
9470 mm
(372.83 in)
9455 mm
(372.24 in)
Height (with attachment)
2960 mm
(116.53 in)
2960 mm
(116.53 in)
3035 mm
(119.49 in)
CX210B (NLC type, standard boom)
Arm (dipper)
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Lenght (without attachment)
5055 mm
(199.01 in)
5055 mm
(199.01 in)
5055 mm
(199.01 in)
Lenght (with attachment)
9500 mm
(374.01 in)
9590 mm
(377.56 in)
9590 mm
(377.5 in)
Height (with attachment)
2990 mm
(117.72 in)
3090 mm
(121.65 in)
3200 mm
(125.98 in)
CX210B (NLC type, articulated boom)
Arm (dipper)
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Lenght (without attachment)
5055 mm
(199.01 in)
5055 mm
(199.01 in)
5055 mm
(199.01 in)
Lenght (with attachment)
9500 mm
(374.01 in)
9570 mm
(376.77 in)
9560 mm
(376.38 in)
Height (with attachment)
2990 mm
(117.72 in)
2990 mm
(117.72 in)
3035 mm
(119.49 in)
