Case CX210B - Work Unit Specifications

Issued 09-2014
1002-22
Work Unit
Model..................................................................................................................................................Backhoe attachment
Components / dimensions / working dimensions
CX210B (LC type, standard boom)
Standard boom
Standard arm Su-Short arm Short arm
Arm (dipper) length
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Boom length (Standard boom spec.)
5700 mm
224.41 in
Bucket radius
1450 mm
57.09 in
Bucket wrist angle 177°
Maximum digging radius
9900 mm
389.76 in
8960 mm
352.75 in
9420 mm
370.87 in
Maximum digging radius at ground line
9730 mm
383.07 in
8770 mm
345.27 in
9240 mm
363.78 in
Maximum digging depth
6650 mm
261.81 in
5610 mm
220.87 in
6110 mm
240.55 in
Maximum vertical straight wall digging depth
5960 mm
234.64 in
5010 mm
197.24 in
5500 mm
216.53 in
Maximum digging height
9610 mm
378.35 in
9160 mm
360.63 in
9410 mm
370.47 in
Maximum dump height
6810 mm
268.11 in
6330 mm
249.21 in
6590 mm
259.45 in
Minimum swing radius at front
3600 mm
141.73 in
3580 mm
140.94 in
3600 mm
141.73 in
Height for minimum swing radius at front
7640 mm
300.79 in
7710 mm
303.54 in
7690 mm
302.76 in
