Case CX240 - Page 220

HYDRAULICS – CX210/CX240
6 - 31
CX EXCAVATORS
ARM OPERATION
With Anti-Drift and Regeneration
Cylinder Return
Cylinder Supply
From arm2 spool (pump2)
Pump1
From arm hand control
Arm Close
(
In
)
W
Cylinder Supply
Cylinder Return
From arm2 spool (pump2)
Pump1
From arm hand control
Arm O
p
en
(
Out
)
Anti-Drift Valve
Anti-Drift Pilot Valve
