CX EXCAVATORS
CURRENT CONDITION CHK3
Continued
SWITCH INPUT (0=OFF, 1=ON)
Key Switch “ON”
• Washer switch is a momentary switch. It is “ON” only while the switch is
being pressed.
• The travel alarm switch is a 2-position rocker switch and is “ON” in one
position and “OFF” in the other.
• The auxiliary hydraulic mode switch is a 3-position rocker switch.
SW6 0 0 0 0
• Window washer switch
• Travel alarm off/on switch
• Auxiliary Hyd. Mode switch
• Not used
