Case CX240B - Digging Force Specifications (ISO 6015)

Issued 09-2014
1002-31
Digging force (ISO 6015)
CX210B (LC, NLC type), CX230B
Arm (dipper)
2940 mm
(115.75 in)
1900 mm
(74.80 in)
2400 mm
(94.49 in)
Arm (dipper) digging force (standard)
103 kN
(23155.3 lbf)
142 kN
(31922.9 lbf)
123 kN
(27651.5 lbf)
Arm (dipper) digging force (power up)
110 kN
(24729 lbf)
152 KN
(34171 lbf)
132 kN
(29674.8 lbf)
Bucket digging force (standard)
142 kN
(31922.9 lbf)
142 kN
(31922.9 lbf)
142 kN
(31922.9 lbf)
Bucket digging force (power up)
152 kN
(34171 lbf)
152 kN
(34171 lbf)
152 kN
(34171 lbf)
CX210B (LR type)
Arm (dipper)
6400 mm
(251.97 in)
Arm (dipper) digging force
46 kN
(10341.2 lbf)
Bucket digging force
65 kN
(14612.6 lbf)
CX240B (LC, NLC type)
Arm (dipper)
3000 mm
(118.11 in)
2500 mm
(98.42 in)
3520 mm
(138.58 in)
Arm (dipper) digging force (standard)
120 kN
(26977.1 lbf)
141 kN
(31698.1 lbf)
107 kN
(24054.6 lbf)
Arm (dipper) digging force (power up)
129 kN
(29000.3 lbf)
151 KN
(33946.1 lbf)
115 kN
(25853 lbf)
Bucket digging force (standard)
162 kN
(36419 lbf)
162 kN
(36419 lbf)
162 kN
(36419 lbf)
Bucket digging force (power up)
174 kN
(39116.8 lbf)
174 kN
(39116.8 lbf)
174 kN
(39116.8 lbf)
CX240B (LR type)
Arm (dipper)
8000 mm
(314.96 in)
Arm (dipper) digging force
44 kN
(9891.6 lbf)
Bucket digging force
77 kN
(17310.3 lbf)
