Case CX350C - General Specifications

INTRODUCTION
Generalspecication
Engine
Type
Water-cooled,4-cyclediesel,6-cylinderinline,Highpressure
commonrailsystem(electriccontrol),Turbochargerwithair
cooledintercooler
Model
ISUZUGH-6HK1XKSS
(ISO9249)200kW(271.924Hp)(2000RPM)
Ratedywheelhorse
power
(ISO14396)212kW(288.240Hp)(2000RPM)
Pistondisplacement7.790L(2.05790USgal)
(ISO9249)983N·m(725.02lbft)(1500RPM)
Maximumtorque
(ISO14396)1020N·m(752.313lbft)(1500RPM)
Boreandstroke
115mm(4.528in)x125mm(4.921in)
Voltage
24V
Alternator50A
Starter
24V5.0kW
Hydraulicsystem
Mainpumps
2variabledisplacementaxialpistonpumpswithregulatingsystem
Max.oilow
2x300L/min(79.25USgpm)(2000RPM)
34.3MPa(4975.2psi)
Boom/Arm/Bucket
37.3MPa(5410.36psi)withautopowerup
Swingcircuit30.4MPa(4409.520psi)
Workingcircuitpressure
Travelcircuit
34.3MPa(4975.2psi)
Pilotpump
1gearpump
Max.oilow
30L/min(7.925USgpm)
Workingcircuitpressure
3.9MPa(565.7psi)
Controlvalves
WithBoom/Armholdingvalve
One4-spoolvalveforRighttracktravel,Bucket,BoomandArmacceleration
One5-spoolvalveforLefttracktravel,Auxiliary,Swing,BoomaccelerationandArm
Swingdevice
Motor
Fixeddisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Finaldrive
Planetarygearreduction
TurntablebearingBallbearingtypewithinternalgear
Maximumswingspeed
10RPM
Swingtorque112000N·m(82606.96lbft)
CylindersNO.ofcylinders–boreXRoddiameterXStroke
Boom
2xØ145mm(5.709in)-Ø100mm(3.937in)-1495mm(58.858in)
Arm
1xØ170mm(6.693in)-Ø120mm(4.724in)-1748mm(68.82in)
Bucket
1xØ150mm(5.906in)-Ø105mm(4.134in)-1210mm(47.638in)
Coolingsystem
Fan
Ø850mm(33.465in)with6-blades
Radiatorcapacity
130.6kW
Fintype
Corrugatedn(wavytype)
Finspace1.75mm(0.0689in)
Longlifecoolant
Coolant55%,Water45%
Oilcoolercapacity
78.9kW
Fintype
Corrugatedn(wavytype)
Finspace1.75mm(0.06890in)
Intercoolercapacity
28.6kW
Fintype
Corrugatedn(wavytype)
Finspace2.5mm(0.0984in)
Fuelcoolercapacity
1.7kW
4802442623/05/2016
18
