INTRODUCTION
Polycarbonateroofhatch&Sunshade
Autoair-conditioner
TopguardOPGlevel1(inCABstructure)
Roll-overprotectivestructure(ROPS)
Operator'sseat
Lowfrequencymechanicalsuspensionwithhelicalspringsanddoubleactinghydraulicdamper.(Achieves
ISO7096incategoryEM6)
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
SeatheightadjustmentAdjustablepivotingarmrestslinkedtoconsoles
Adjustableheadrest
Retractableseatbelt
AdjustablelumbarsupportControlconsolesadjustindependentlyofseat
Others
Rearviewmirror(Cabside&Rightside)
Undercarriage
Travelmotor
Variabledisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
5.4km/h(3.36mph)(Automatictravelspeedshifting)
Travelspeeds
Low
3.4km/h(2.113mph)
Drawbarpull263kN(59124.752lb)
Numberofcarrierrollers(eachside)
2
Numberofcarrierrollers(eachside)
7
Numberofshoes(eachside)
45
Typeofshoe
Triplegrousershoe
Linkpitch216mm(8.504in)
Widthofshoe
600mm(23.622in)(S.T.D)
Grade-ability70%(35°)
Mass
Operatingmass36100kg(79586.877lb)
with2.63m(8.629ft)Arm,1.6m³Bucket,600mm(23.622in)grousershoe,operator,lubricant,coolant
andfullfueltank
Shippingmass34000kg(74957.169lb)
Operatingmass-(operatormass[75kg(165.35lb)])+90%offuelmass[430kg(947.99lb)]+bucket
mass[1580kg(3483.304lb)])
Counterweightmass7400kg(16314.207lb)
Groundpressure
0.073MPa(10.5886psi)
with2.63m(8.629ft)HDArm,1.6m³Bucket,600mm(23.622in)grousershoe
Diggingforce(with1.6m³HDBucket)(ISO6015)
[2.63m(8.6286ft)]
HDArm
[2.21m(7.2507ft)]
HDArm
[3.25m
(10.6627ft)]HD
Arm
[4.04m
(13.2546ft)]Arm
Armdiggingforce
196kN
(44062.553lb)
228kN
(51256.439lb)
165kN
(37093.476lb)
141kN
(31698.061lb)
Withautopowerup
213kN
(47884.305lb)
248kN
(55752.618lb)
179kN
(40240.801lb)
153kN
(34395.768lb)
Bucketdiggingforce
232kN
(52155.675lb)
232kN
(52155.675lb)
232kN
(52155.675lb)
232kN
(52155.675lb)
Withautopowerup
252kN
(56651.854lb)
252kN
(56651.854lb)
252kN
(56651.854lb)
252kN
(56651.854lb)
