INTRODUCTION
Valveforleft/rightoperations
Manufacturer
KawasakiHeavyIndustries,Ltd.
Operatingpressure3.92MPa(569psi)
Secondarypressure0.64-2.45MPa(92.8320-355psi)primaryshorttype
1,3port
19°
Operatingangle
2,4port
25°
Weight
1.9kg(4.1888lb)
Valvefortraveloperation
Manufacturer
KawasakiHeavyIndustries,Ltd.
Operatingpressure3.92MPa(569psi)
Secondarypressure0.64-2.45MPa(92.8320-355psi)primaryshorttype
Operatingangle12.4°
Weight
5.5kg(12.1254lb)
Remotecontrolvalveforoptionoperations
ManufacturerNishinaIndustrialCo.,Ltd.
Operatingpressure3.92MPa(568.610psi)
Secondarypressure0.64-2.45MPa(92.8-355.4psi)primaryshorttype
Operatingangle11.4°–12.6°
Portsize
P ,T ,A,B,C1,C2G1/4
Weight
1.7kg(3.748lb)
Remotecontrolvalvecharacteristicdiagram
Operationremotecontrolvalvecontroldia-
gram
Ports1,3
A.
Secondarypressure[MPa(psi)]
B.
Pushrodstroke[mm(in)]
C.Operatingangle[deg.]
1
Secondarypressure
SMIL14CEX0416AB1
Ports2,4
A.
Secondarypressure[MPa(psi)]
B.
Pushrodstroke[mm(in)]
C.Operatingangle[deg.]
1
Secondarypressure
SMIL14CEX0418AB2
