INTRODUCTION
PortD
BackwardleftG1
PortTDrainport
G1/2
PortPPilotport
G1/4
Weight
55.5kg(122.357lb)
Backhoeattachment
Cylinder
Boomcylinder
Cylinderbore∅ 145mm(5.709in)
Roddiameter
∅ 100mm(3.973in)
Maximumretractedlength
2090mm(82.283in)
Stroke1495mm(58.858in)
Weight
285kg(628.3174lb)
Armcylinder
Cylinderbore∅ 170mm(6.693in)
Roddiameter
∅ 120mm(4.724in)
Maximumretractedlength
2445mm(96.260in)
Stroke1748mm(68.819in)
Weight
510kg(1124.3575lb)
Bucketcylinder
Cylinderbore∅ 150mm(5.906in)
Roddiameter
∅ 105mm(4.134in)
Maximumretractedlength
1870mm(73.622in)
Stroke1210mm(47.638in)
Weight
288kg(634.9313lb)
