INTRODUCTION
*Speciedamountofwaterandlubricatingoilareincluded.
*Thefueltankisfull.
Standalonepartweight
Componentname
Weight
1
Travelunit(travelmotor+drivesprocket)512kg(1128.767lb)
3
Take-uproller168kg(370.377lb)
4
Upperroller42kg(92.594lb)
5
Lowerroller
60kg(132.277lb)
6
Swingunit(includingpinion)466kg(1027.354lb)
7
Turntablebearing
541kg(1192.701lb)
8
Engine(includingengineoil)640kg(1410.958lb)
9Radiator
144kg(317.466lb)
10
Hydraulicpump
188kg(414.469lb)
11Fueltank
270kg(595.248lb)
12
Hydraulicoiltank
195kg(429.901lb)
13
Controlvalve
199kg(438.720lb)
14
Centerjoint56kg(123.459lb)
15Boom
2738kg(6036.257lb)
Shoeweight(perside)
Componentname
Weight
1
600mm(23.62in)grousershoe2091kg(4609.866lb)
2
800mm(31.50in)grousershoe2455kg(5412.349lb)
Armweight
Componentname
Weight
1
Standardarm(HDEM3O1GB)1461kg(3220.954lb)
2
Standardarm(HDEM3O12GB)1464kg(3227.568lb)
3
Shortarm(HDEM3O1GB)1316kg(2901.283lb)
4
Shortarm(HDEM3O12GB)1317kg(2903.488lb)
5
Ultra-shortArm(HDEM3O1GB)1207kg(2660.980lb)
6
Ultra-shortArm(HDEM3O12GB)1209kg(2665.389lb)
7
LongArm(EM3O1)1495kg(3295.911lb)
8
LongArm(EM3O12)1500kg(3306.934lb)
