INTRODUCTION
Cushionvalve(heatcircuit,withshuttlevalve)
ManufacturerYanagisawaSeikiMFG.Co.,Ltd.
Portsize
G3/8(A-Pport)
G1/4(Q-Vport)
Weight
12.5kg(27.5578lb)
Selectorvalve(option)
2WAY
ManufacturerNishinaIndustrialCo.,Ltd.
Ratedowrate25l/min(6.604USgpm)
OperatingmethodISO
Portsize
G3/8
Weight
4kg(8.8185lb)
Centerjoint
OperatingpressureHigh-pressurepassage(ABCD)34.3MPa(4975psi)
Drainport(T)1MPa(145psi)
Pilotport(P)3.9MPa(566psi)
Flowrate
High-pressurepassage(ABCD)360L/min(95.102USgpm)
Drainport(T)40L/min(10.567USgpm)
Pilotport(P)31L/min(8.189USgpm)
PortAForwardright
G1
PortB
ForwardleftG1
PortC
Backwardright
G1
PortD
BackwardleftG1
PortTDrainport
G1/2
PortPPilotport
G1/4
Weight
55.5kg(122.3566lb)
