Case CX350D - General Specification - Main Equipment

INTRODUCTION
Generalspecication–Mainequipment
Lowercomponent
Travelunit
ManufacturerKYBCorporation
MotortypeVariabledisplacementpistonmotor
Automatic2-speedswitchoverwithparkingbrake
Absorptionamount
181.3-106.7cm³/rev(11.1-6.5in³/rev)
Operatingpressure34.3MPa(4975psi)
Operatingow292.5l/min(292.500USgpm)
Braketorque
41.285N·mormore(reductiongearincluded)
Reliefvalvesetpressure35.3MPa(5120psi)
Automatic2-speedswitchoverpressure
25-27MPa(3597-3884psi)
Reductiongear
ReductiongeartypePlanetarygear2-stagereductiongear
Reductionratio65.783
Dryweight
394kg(868.621lb)
Take-uproller
Weight
168kg(370.377lb)
Upperroller
Weight
42kg(92.594lb)
Lowerroller
Weight
61kg(134.482lb)
Recoilspring
Item
Weight
Quantity
Yoke
78.6kg(173.2833lb)
1
SemsBM16X501.0kg(2.205lb)
4
Threadedrod
50.7kg(111.7744lb)
1
DeepgroovenutM64
1.9kg(4.1888lb)
1
SPpin10x1000.1kg(0.2205lb)
1
Recoilspring
124.6kg(274.6960lb)
1
Greasecylinderassembly41.1kg(90.6100lb)
1
SemsBM16X650.3kg(0.6614lb)
2
Assembly(total)298kg(656.9775lb)
Mountinglengthofspring781mm(30.7480in)
Shoes
Weightorquantity
700grouser(shoe)2473kg(5452.032lb)
Link1pair
Shoes
48
Bolt192
Nut192
800grouser(shoe)2618kg(5771.702lb)
Link1pair
Shoe
48
Bolt192
Nut192
4784302602/03/2015
22
