INTRODUCTION
Diggingforce(with1.4m³bucket)(ISO6015)
3.25m(10.6627ft)Arm2.63m(8.6286ft)Arm4.04m(13.2546ft)Arm
Armdiggingforce164.5kN(36981.1lb)194.7kN(43770.3lb)140.0kN(31473.3lb)
Withautopowerup178.8kN(40195.8lb)211.7kN(47592.1lb)152.2kN(34215.9lb)
Bucketdiggingforce229.7kN(51638.6lb)229.7kN(51638.6lb)229.7kN(51638.6lb)
Withautopowerup249.8kN(56157.3lb)249.8kN(56157.3lb)249.8kN(56157.3lb)
Dimensions
3.25m(10.6627ft)Arm2.63m(8.6286ft)Arm4.04m(13.2546ft)Arm
Overalllength(without
attachment)
6010mm(236.614in)6010mm(236.614in)6010mm(236.614in)
Overalllength(with
attachment)
11170mm(439.764in)11220mm(441.732in)11190mm(440.551in)
Overallheight(totopof
boom)
3470mm(136.614in)3630mm(142.913in)3620mm(142.520in)
Overallheight(totopof
Cab)
3180mm(125.197in)3180mm(125.197in)3180mm(125.197in)
Overallheight(totopof
guardrail)
3470mm(136.614in)3470mm(136.614in)3470mm(136.614in)
Upperstructureoverall
width
3030mm(119.291in)3030mm(119.291in)3030mm(119.291in)
Upperstructureoverall
width(withcatwalks–
option)
3590mm(141.339in)3590mm(141.339in)3590mm(141.339in)
Swing(rearend)radius3550mm(139.764in)3550mm(139.764in)3550mm(139.764in)
Clearanceheightunder
upperstructure
1210mm(47.638in)1210mm(47.638in)1210mm(47.638in)
Minimumgroundclearance
470mm(18.504in)470mm(18.504in)470mm(18.504in)
Wheelbase(Centerto
centerofwheels)
4040mm(159.055in)4040mm(159.055in)4040mm(159.055in)
Crawleroveralllength4980mm(196.063in)4980mm(196.063in)4980mm(196.063in)
Trackgauge
2600mm(102.362in)2600mm(102.362in)2600mm(102.362in)
Undercarriageoverallwidth
[with800mm(31.496in)
shoes]
3400mm(133.858in)3400mm(133.858in)3400mm(133.858in)
Crawlertracksheight1090mm(42.913in)1090mm(42.913in)1090mm(42.913in)
Workingranges
3.25m(10.6627ft)Arm2.63m(8.6286ft)Arm4.04m(13.2546ft)Arm
Boomlength
6450mm(253.937in)6450mm(253.937in)6450mm(253.937in)
Bucketradius
1680mm(66.142in)1680mm(66.142in)1680mm(66.142in)
Bucketwristaction
173°173°173°
MaximumreachatGRP
10980mm(432.283in)10450mm(411.417in)11710mm(461.024in)
Maximumreach
11170mm(439.764in)10650mm(419.291in)11900mm(468.504in)
Max.diggingdepth
7340mm(288.976in)6720mm(264.567in)8140mm(320.472in)
Max.diggingheight
10380mm(408.661in)10280mm(404.724in)10650mm(419.291in)
Max.dumpingheight
7240mm(285.039in)7110mm(279.921in)7530mm(296.457in)
