INTRODUCTION
Operatorenvironment
Operator'scab
Smoothandroundshapedesigncab,fabricatedbypresswork
Safetyglassforallwindows
Shock-lesscabsuspensionby4-pointuidmounting
Slidingfrontwindowwithautolock
Built-intypefull-colorLCDmonitordisplay
Membraneswitchonmonitordisplay
Windshieldwiper&washer
AM/FMRadiowithauto-tuner&auxiliaryport
Floormat
Polycarbonateroofhatch&Sunshade
Autoair-conditioner
Roll-overprotectivestructure(ROPS)
TopguardOPGlevel1(inCABstructure)
Operator'sseat
Lowfrequencyairsuspensionwithairspringsanddoubleactinghydraulicdamper.(AchievesISO7096
incategoryEM6)
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
Seatheightadjustment
Adjustablepivotingarmrestslinkedtoconsoles
AdjustableheadrestRetractableseatbelt
Adjustablelumbarsupport
Controlconsolesadjustindependentlyofseat
Others
Rearviewmirror(Cabside&Rightside)
RearviewCamera
Undercarriage
Travelmotor
Variabledisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
5.5km/h(3.4mph)(Automatictravelspeed
shifting)
Travelspeeds
Low
3.3km/h(2.1mph)
Drawbarpull273kN(61373lb)
Numberofcarrierrollers(eachside)
2
Numberoftrackrollers(eachside)
8
Numberofshoes(eachside)
48
Typeofshoe
Triplegrousershoe
Linkpitch216mm(8.504in)
Widthofshoe
800mm(31.496in)(S.T.D)
Grade-ability70%(35°)
Mass
Operatingmass37400kg(82452.89lb)
with3.25m(10.6627ft)Arm,1.4m³Bucket,800mm(31.496in)grousershoe,operator,lubricant,
coolantandfullfueltank
Shippingmass35700kg(78705.03lb)
Operatingmass-(operatormass[75kg(165.35lb)]+90%offuelmass+bucketmass[1180kg
(2601.45lb)]
Counterweightmass7400kg(16314.21lb)
Groundpressure
0.052MPa(7.543psi)
with3.25m(10.6627ft)Arm,1.4m³Bucket,800mm(31.496in)grousershoe
