INTRODUCTION
Uppercomponent
Swingunit
Swingmotorassembly
Swingmotor
Manufacturer
KawasakiPrecisionMachineryLtd.
MotortypeFixeddisplacementpistonmotor
Withparkingbrake
Absorptionamount
180.1cm³/rev(10.99in³/rev)
Operatingpressure30.4MPa(4409.5psi)
Operatingow290L/min(76.6099USgpm)
Mechanicalbraketorque
1010.80N·m(745.53lbft)ormore
Brakeoffpressure3.1MPa(449.7psi)orless
Reliefvalvesetpressure30.4MPa(4409.5psi)
Swingreductiongear
ReductiongeartypePlanetarygear2-stagereductiongear
Reductionratio27.143
Dryweight
437kg(963.420lb)
Turntablebearing
Numberofteeth
92
Weight
541kg(1192.701lb)
Counterweight
Weight
7402kg(16318.617lb)
