INTRODUCTION
Engine-related
Engine
EnginemodelnameIsuzu6HK1Xdieselengine
Enginetype
4-cycle,water-cooled,overheadcamshaft,verticalin-line,direct
injectiontype(electronicscontroltype)
Numberofcylinders-diameter-stroke6-∅ 115mm(4.53in)-125mm(4.92in)
Totaldisplacement
7.79l(7.790USgal)
Compressionratio
17.5
Ratedoutput
198kW(269.20Hp)/1900RPM
Maximumtorque
983N·m(725.02lbft)/1500RPM
Fuelconsumptionratio
231g/kWh
Enginedryweight
About690kg(1521.190lb)
Enginedimension
L1388mm(54.646in)-W1047mm(41.220in)-H1194mm
(47.008in)
Coolingfan850mm(33.465in)-suctiontype-6bladesresinandsteel
Withbellmouth-typefanguide
Pulleyratio
0.8(reduction)
Charginggenerator24V50AACtype
Startermotor24V5kW(6.8Hp)reductiontype
Coolantcapacity14.5l(3.830USgal)
OilpancapacityMax:46L(12.152USgal) Min:36L(9.510USgal)KSH10440
DirectionofrotationRight(viewedfromfanside)
CompliantwithJISD0006-2010
Aircleaner(doubleelement)
Manufacturer
NipponDonaldson,Ltd.
Element(outer)
Filteringareasize
12.70m²(136.70ft²)
Element(inner)
Filteringareasize
1.74m²(18.73ft²)
Weight
13kg(28.660lb)
Radiator
ManufacturerTokyoRadiatorMFG.Co.,Ltd.
Weight
44.7kg(98.547lb)
Oilcooler
Oilvolume16L(4.227USgal)
Weight
19.8kg(43.652lb)
Radiator
Coolantcapacity11.5L(3.038USgal)
Weight
18.1kg(39.904lb)
Aircooler
Capacity
-
Weight
1.0kg(2.205lb)x2
Fuelcooler
Capacity0.3L(0.079USgal)x2
Totalweight
180kg(396.832lb)
SCR
ManufacturerTokyoRadiatorMFG.Co.,Ltd.
Ureacapacity
164.5L(43.456USgal)
Weight
14.1kg(31.085lb)
