INTRODUCTION
Fintype
Corrugatedn(wavytype)
Finspace2.25mm(0.0886in)
Coolingfandrivesystem
Pump1vanepump
Motor
Fixeddisplacementaxialpistonmotor
Filters
Suctionlter
105μm
Returnlter
6μm
Pilotlinelter
8μm
Hydrauliccontrols
Boom/Arm/Bucket/SwingPilotpressurecontrolsystem(ISOcontrolpattern)
Travel
Pilotpressurecontrolsystem
SP-mode
H-mode
Workmodeselect
Auto-mode
Travelmodeselect
2-speedtravel
Attachmentcushioncontrol
Hydrauliclock(gatelock,leftsidetiltconsole)
Fanreverserotationsystem
Electricalsystem
Enginecontrol
Dialtypethrottlecontrol
Onetouchidle/Autodeceleration/Autoidleshutdownsystem
Emergencystop
Monitorsystem
Messagedisplay(Caution,condition,etc…)
Workmodedisplay(SP ,H,Auto)
Machinecondition(Powerboost,etc…)
Alarmdisplayandbuzzer
Watertemperature
Hydraulicoiltemperature
Fuellevel
Diagnosissystem
Rear&Rightsideviewcameraimage
Wireharness
Waterprooftypeconnector
Safety
Doublehorn
Battery
2x12V128A·h/5HR
Lights
Upper
24V70Wx1
Boom24V70Wx2
Workinglight
Cab
24V70Wx2
Operator'scabroom
24V10Wx1
Operatorenvironment
Operator'scab
Smoothandroundshapedesigncab,fabricatedbypresswork
Safetyglassforallwindows
Shock-lesscabsuspensionby4-pointuidmounting
Slidingfrontwindowwithautolock
Built-intypefull-colorLCDmonitordisplay
