Case CX490C - Dimension - CX490 C STD version

INTRODUCTION
Dimension
CX490CCrawlerexcavatorsSTDversion(TIER3)-TurkishmarketAPAC
Standardarm[3.38m(11.0892ft)]
NOTE:Numbersaresubjecttochangewithoutnoticeduetodesignchangeorotherreason.
Thediagramsgivevaluesthatincludetheshoelugheight“a”[36mm(1.417in)].
F8877C5D1
b.
Withcatwalk-option
e.
540mm(21.260in)
c.
1570mm(61.811in)
f.
3560mm(140.157in)
d.
1490mm(58.661in)
