Case CX490C - Dimension - Standard Arm (LC)

INTRODUCTION
Dimension
CX490CCrawlerexcavatorsLCversion(TIER3)-TurkishmarketAPAC
Standardarm[3.38m(11.0892ft)]
NOTE:Numbersaresubjecttochangewithoutnoticeduetodesignchangeorotherreason.
Thediagramsgivevaluesthatincludetheshoelugheight“a”[36mm(1.417in)].
6948EAB31
b.
Withcatwalk-option
e.
540mm(21.260in)
c.
1570mm(61.811in)
f.
3560mm(140.157in)
d.
1490mm(58.661in)
4809839920/01/2017
46
