Case FARMALL 110A - International Symbols

1-GENERALINFORMATION
Internationalsymbols
Asaguidetotheoperationofthemachine,variousuniversalsymbolshavebeenutilizedontheinstruments,controls,
switches,andfusebox.Thesymbolsareshownbelowwithanindicationoftheirmeaning.
Heaterplugfor
coldstart
Turningsignal
PowerTake-Off
(PTO)
Reactioncontrol
Alternator
charging
Activatedmemory
Transmissionin
neutral
Accessories
socket
Fuellevel
Turnsignals
Creeperselection
Implementsocket
Automaticfuel
shut-off
Turnsignals-one
trailer
Lowspeed
selection
Percentageslip
Enginespeed
(rpmx100)
Turnsignals-two
trailers
Highspeed
selection
Raisingofthe
hydrauliclift
Hourmeter
Windshield
washer
Roadspeed
Rearhitchlower
Engineoil
pressure
Windscreenwash
wipe
DifferentialLock
Hydrauliclift
heightthreshold
Enginecoolant
temperature
Heating
temperature
control
Rearaxleoil
temperature
Hydrauliclift
disabled
Coolantlevel
Cabrecirculation
fan
Transmissionoil
pressure
Transmission
ltersand
hydrauliclters
Machinelights
Airconditioner
AuxiliaryFront
WheelDrive
(AFWD)operated
Remotecontrol
valveextension
Mainbeamhead
AirFilter
Restriction
Warning!
Remotecontrol
valvecommand
retraction
Lowbeam
Parkingbrake
Dangerwarning
lights
Remotecontrol
valveotation
Worklamps
Brakeuidlevel
Variablecontrol
Malfunction!See
Operator’s
Stoplamp
Trailerbrake
Pressurized!
Opencarefully
Malfunction!
(alternative
symbol)
Klaxon
Warning!
Corrosive
substance
Positioncontrol
Brakeuidlevel
