Case JX80 - Engine Removal - Final Separation; Separating Engine from Transmission; Spacer Removal

18 SECTION 10 -- ENGINE -- CHAPTER 1
84176554 -- 03--2008
47. Seperate the engine from the transmission with
the tool 380000569.
1 2
44
48. Remove the spacer located between the engine
and the transmission.
45
49. Insert the fixed under the balast support and
secure the front wheels with wooden blocks.
1
2
46
50. Loosen the corresponding retaining clamp (1)
and extract the pipes. And remove the bracket
(2).
47
