SECTION 2 - OPERATION
2-9
Pull out lock handle (E) to unlock the lock pin and turn
until the lock handle rests against the base stop (one
on each side).
CAUTION
Pinch risk.
The locking wheel is spring loaded. Handle
carefully.
• Release the brakes.
• Move the control joystick to the lowering position,
so that the lifting cylinders are completely
retracted.
0181
E
20
Roll back the attachment or bucket carefully. This will
make the rear of the loader lift, and come loose and
lift upward from the subframe.
• Stop the tractor and relieve the oil pressure to the
lift cylinders, using the control valve.
• Disconnect the hose connection(s) and install
dust cover on the couplings.
• Reverse the tractor carefully until it is completely
clear from the loader.
IMPORTANT: Make sure that you position the hoses
in the hose holder on the RH boom arm so that they
do not catch on the tractor.
0141
21
