Engine-Engineandcrankcase
37.Removethemufermountingbracket(1).
RAIL14SSL0844BA22
38.Disconnecttheleftcoolantline(4)andrightcoolant
line(2).
39.DisconnecttheDEFhose(1).
40.Disconnecttheinjector(3).
41.Removeanywireties,P-clamps,andretainersthat
aresecuringthesewirestothemufermounting
bracket.
RAIL14SSL0857BA23
42.Removetheexhaustclamp(2).
43.RemovetheDOCmufer(1).
RAIL14SSL0787BA24
4768516124/06/2015
10.1[10.001]/12
