Engine-Engineandcrankcase
65.Attachthemount(1)fortheoildipsticktotheshroud.
RAIL14SSL0847BA32
66.ApplyLOCTITE®243™tothethreadsofthebolts(2),
andinstallthefan(1).
RAPH12SSL0062AA33
67.Readjusttheshroudifthereisnot13mm(1/2in)of
clearance(A)betweenthefanbladesandtheshroud.
RAPH14SSL0776BA34
4768516124/06/2015
10.1[10.001]/27
