Engine-Engineandcrankcase
68.Adjusttheserpentinebeltforthealternatorbyturning
theadjustingbolt(3).
NOTE:Thealternatorbeltdoesnothaveatensioningpro-
cedure.Thealternatorisadjustedallthewaytothestop.
69.Torquetheadjustingbracketbolt(2)to50N·m(37lb
ft).
70.Torquethejamnutfortheadjustingbolt(3)to30N·m
(22lbft).
71.Torquethemountingbolts(1)to50N·m(37lbft).
RCPH11SSL038AAP35
72.IfyourmachineisequippedwithA/C,adjustthebelt
fortheA/Ccompressorbyturningtheadjustingscrew
(1).
NOTE:Thebeltistightenedcorrectlywhenaforceof
1.0kg(2.2lb)isappliedtothecenteroftheofthespanof
thebeltwitha3mm(1/8in)ofdeection.
73.Tightenthemountingbolts(2).
RAPH12SSL0064BA36
74.Placetheradiator(3)insidetheshroud,butdonot
installthehardware.
75.Attachthehoses(1)totheradiator.T orquethehose
clamps(2)to3-4N·m(27-35lbin).
RAIL14SSL0797BA37
