HYDRAULIC,PNEUMATIC,ELECTRICAL,ELECTRONICSYSTEMS-PRIMARYHYDRAULICPOWERSYSTEM
Controlvalve-GeneralspecicationoftheRide/GlideControl
Valve
Solenoidoperated,4way,2position,directacting,spooltypehydraulic
cartridgevalve.
ValveConguration:
Flow=22.7l/min(6USgpm).
HydraulicRequirements:
SystemPressure=210bar(3045psi).
OperatingVoltage=14V
MaximumPower=22W
Polarity=Power:Pin1orA,Ground:Pin2orB
ElectricalRequirements:
Solenoidconnectiontype=DuetschDTseries.
OperatingT emperatureRange:-30-107°C(-22-225°F)
(1)TankReturn
(2)LiftCylinderRodPort
(3)Accumulator
PortIdenticationChart:
(4)LiftCylinderBasePort
8442386625/07/2011
A.10.A/16
