— 54 —
Item Code No. Parts Name Specification Version Q R
R41 Carbon film resistor CR-25-5.6KOHMJ-T 1 X
R48 Metal film resistor CRH200-FH24-J-101 1 X
R35 Metal film resistor CRH100-FH11J-2R2 1 X
RA3 Module resistor MS5635F 1 X
RA1 Module resistor MS1038F 1 X
RA2 Module resistor MS1036F 1 X
C7,8,11,14, TF capacitor ECQV1H104JZ3 10 X
C17,18,22,23,
C24,26
C6 2807 3533 Electrolytic capacitor RE2-25V330MMA-T2 1 C
C5 2807 3540 Electrolytic capacitor RE2-25V331MMA-T2 1 C
C3 2807 3547 Electrolytic capacitor RE3-35V470MMA-T2 1 C
C25 2807 3554 Electrolytic capacitor RE2-35V221MMA-T2 1 C
C2 2807 3561 Electrolytic capacitor RE3-35V332M-T 1 C
C13,20 Ceramic capacitor RT-HE50TKYB102K-T 2 X
C12 Ceramic capacitor RT-HE40TKYB471K-T 1 X
C4,9,10,19 Ceramic capacitor RT-HE40TKYB101K-T 4 X
C21 Ceramic capacitor RT-HE12TKYB103K-T 1 X
C16 Ceramic capacitor RT-HE40TKCH150J-T 1 X
C15 Ceramic capacitor RT-HE40TKCH120J-T 1 X
CA1,2,4 Module capacitor CNB5X101K 3 X
C1 Mylar capacitor 50F2S683J 1 X
CA3 Module capacitor CNB7X101K 1 X
L1 Inducter OWA1419-681K 1 X
F1 3000 7196 Fuse 218002 1 A
F1 3631 0329 Fuse 237002 US 1 A
F2 3631 0328 Fuse UL-TSCR-0.8A 1 A
F1 3640 2331 Fuse clip UF-0033 2 X
IC6 3000 7567 IC socket DILB8P-8JK 1 X
BZ1 3122 1589 Sounducer PKM22EPP-2002 1 C
CN9 3500 3371 Connector 2P IL-G-2P-S3T2-E 1 C
CN2 3500 5831 PCB connector 52045-2045 1 C
CN13 3500 5832 PCB connector 5229-22APB 1 C
CN11 3500 5846 Connector 53253-0210 1 C
CN12 3501 6244 Connector B2B-PH-K-S 1 C
CN1 3510 2680 Pin ass'y 2P 5277-02A 1 C
Heat sink OSH-1625-SP 1 X
CN5,6 Fasten tab 22019 2 X
PCB E245-1 (without components) E240345-1 1 X
2. UPPER CASE BLOCK
1 6247 8807 Screw 4X85 ZMC-3 1 X
2 5460 0021 Washer 4X9X0.8 ZMC-3 1 X
3 6220 2505 Display bush E310377-1 1 X
67 6221 3783 FFC joiner B-E240 E411354-2 1 A
4 6247 6455 Upper case E140123-1
Except Europe,
UK,Germany 1 X
4 6247 8849 Upper case E140123-3
Europe, UK,
Germany 1 X
5 6247 6665 Display plate E246B E140124-3 1 X
3. MAIN DISPLAY BLOCK
2320 1365 LED HDSP-5621#S02 4 B
2320 1366 LED HLMP-S500 2 B
