PARTS PRICE LIST
AP-21
N Item Code No. Part Name Specification Q Price Code R Remarks
Main PCB
BT1
3815 0794 BATTERY / LITHIUM CR2032/1VC1 1 AI B
D1 - D4
2390 2576 DIODE / SCHOTTKY RB501V-40TE-17 4 AB B
D5
2390 2576 DIODE / SCHOTTKY RB501V-40TE-17 1 AB B
D6
2360 3057 DIODE / ZENER UDZTE-173.3B 1 AA B
IC1
2105 1120 IC / L-MOS TC7S08F(TE85R) 1 AB B
N
IC2
2105 6657
IC / C-MOS
TC74HC10AF(TP1) 1 AB B
IC3
2011 8806 IC / C-MOS TC74HC04AF(TP1) 1 AC B
IC5
2114 4060 IC / MONOLITHIC MB3771PF-EF 1 AK B
LSI1
2011 5222 LSI HD6435328RC13F 1 CB A
LSI10
2011 5194 LSI HG52E35P 1 BJ A
N
LSI2
2012 6404 LSI LH532KU3 1 AT A
LSI3, LSI8 - LSI9
2012 5572 LSI TC55257DFL-70L(EL) 3 AS A
LSI4 - LSI5
2114 4221 LSI UPD6376GS-E1 2 AS A
LSI6
2012 5707 LSI MX23C2410MC-12CA58 1 BO A
LSI7 2012 1316 LSI HG51B155FD-1 1 BU
A
Q1 - Q2
2250 1162 TRANSISTOR 2SA1576AT106R 2 AA B
Q3
2250 1162 TRANSISTOR 2SA1576AT106R 1 AA B
Q4 2252 0637 TRANSISTOR 2SC4081T106R 1 AA
B
SNF1
3025 1505 FILTER / EMI NFM51R00P106 1 AC B
X1
2590 2100 OSCILLATOR CSACS20.00MX040-TC 1 AG B
X2
2590 1043 OSCILATOR AT-49-16.384M 1 AK B
1
6927 5470 PCB ASSY / M425-MA1M M241032*1 1 EM A
Console PCB
D301 - D318
2390 1344 DIODE 1SS133T-77 18 AA B
N
LED301 - LED317
2370 1416 LED SLZ-190B-03-T2 17 AA B
LSI301
2011 0812 LSI UPD65005GF-419 1 AT A
SW301 - SW318
3412 0903 SWITCH / TACT EVQ-21405R 18 AA A
VR301
2765 0280 VOLUME EWA-NAXCH1B14 1 AI A
VR302
2765 2187 VOLUME EWA-NFECH1B54 1 AG A
2
6927 5560 PCB ASSY / M425-CN1,2M M241033*1 1 DD A
Power supply PCB
D401 - D404, D415 2390 2996 DIODE 1SR139-400T-32 5 AA B
D405 - D408 2390 3022 DIODE 3BZ41(LC6-15) 4 AD B
D409 - D414
D417 - D421
2390 1344 DIODE 1SS133T-77 11 AA B
D416 2390 1323 DIODE RB100A-T32-T 1 AC B
D422 - D423 2360 1729 DIODE / ZENER MTZJ5.1AT-77-T 2 AA B
F402 3632 0719 FUSE / UL TIME-LAG UL-TSC-1A-N1 1 AF A For 110 - 127V area
F402 3631 1037 FUSE / TIME-LAG (S)T-1A 1 AE A For 220 - 240V area
F403 - F404 3632 0301 FUSE / UL TIME-LAG UL-TSC-4A-N1 2 AF A For 110 - 127V area
F403 - F404 3632 0049 FUSE / TIME-LAG (S)T-4A 2 AF A For 220 - 240V area
IC401
2114 5794
IC / MONOLITHIC
NJM78M15FA 1 AE B
IC402
2114 5795
IC / MONOLITHIC
NJM79M15FA 1 AG B
IC403
2114 5797
IC / MONOLITHIC
NJM78L05A(T3) 1 AE B
IC404
2114 5796
IC / MONOLITHIC
NJM78M05FA 1 AE B
IC405
2114 1106 IC / HYBRID STK4132MK2 1 BL B
IC406, IC408
IC410, IC411
2114 1799 IC / MONOLITHIC M5218APR 4 AC B
IC409 2114 1421 IC / PHOTO COUPLER PC900V 1 AK B
J401 - J402 3612 0584 JACK YKB21-5012 2 AD A
J403 - J404 3612 0789 JACK YKB21-5010 2 AC A
J405 3501 4816 JACK / DIN YKF51-5051 1 AH B
Q401 - Q404 2254 0551 FET 2SK365-BL(TPE4) 4 AC A
3 6927 5520 PCB ASSY / M425-PS2M M241035*2 DN A For 110 - 127V area
3
6927 5530 PCB ASSY / M425-PS2M M241035*3 DN A
For 220 - 240V area
