N Item Code No. Part Name Specification Q Price Code R Remarks
PS12,PS3,PS4M PCB's
F401 3632 0294 FUSE / UL TIME-LAG MT4-2A-N1 1 AF A For 110 - 127V area
F401 3631 1037 FUSE / TIME-LAG (S)T-1A 1 AE A For 220 - 240V area
N
J406 - J407 3502 2657 JACK / PHONE YKB22-5006 2 AF A
L401 3013 2577 COIL / CHOKE PLAC1522R0R01B1 1 AM C
N
LED401 2370 1417 LED SLP-135B-51 1 AA B
4 6927 5490
PCB ASSY / M425-PS12
M341012*2 1 BS B For 110 - 127V area
4
6927 5500 PCB ASSY / M425-PS12 M341012*3 1 BR B
For 220 - 240V area
5 6927 5540 PCB ASSY / M425-PS3M M341013*1 1 CO B
6 6927 5580 PCB ASSY / M425-PS4M M341014*1 1 BJ B
Keyboard PCB's
N
D701 - D876 2390 3043 DIODE 1S2076TE 176 AA B
N
7 6927 3270 PCB ASSY / M887T-KY1M M240951*1 1 BO C
N
8 6927 3280 PCB ASSY / M887T-KY2M M240952*1 1 BT C
N
9
6927 5610
PCB ASSY / M887T-KY3M M241019*1
1 BM C
Other electrical parts
N
10 3012 1614 TRANSFORMER TE-425-1M1 1 CA B For 110 - 127V area
N
10 3012 1615 TRANSFORMER TE-425-2M1 1 CA B For 220 - 240V area
11 3831 1077 SPEAKER SG16G51BFA 2 BS B
12
3613 0217 RECEPTACLE NC-174-10-C 1 AJ C
Keyboard unit
N
13 6927 3230 KY ASSY M140830*1 1 EO B
N
14 6927 3980 RUBBER / CONTACT AB M240957-1 1 AE A
N
15 6927 3990 RUBBER / CONTACT CB M240958-1 6 AH A
N
16 6927 4000 RUBBER / CONTACT CS M240959-1 1 AH A
N
17 6927 3250 HAMMER ASSY / WHITE KEY M340962*1 52 BF B
N
18 6927 3260 HAMMER ASSY / BLACK KEY M340963*1 36 BF B
N
19 6927 4030 BLACK KEY M140784-1 36 AG A
N
20 6927 4040 WHITE KEY / C M140783-1 7 AH A
N
21 6927 4050 WHITE KEY / D M140785-1 7 AI A
N
22 6927 4060 WHITE KEY / E M140786-1 7 AH A
N
23 6927 4070 WHITE KEY / F M140787-1 7 AI A
N
24 6927 4080 WHITE KEY / G M140788-1 7 AH A
N
25 6927 4090 WHITE KEY / A. M140789-1 7 AH A
N
26 6927 4100 WHITE KEY / B M140790-1 8 AI A
N
27 6927 4110 WHITE KEY / SA M140792-1 1 AM A
N
28 6927 4120 WHITE KEY / SC M140791-1
1 AN A
Mecanical parts
29 6924 5260 BUTTON / POWER M340318-1 1 AA B
30 6919 3241 KNOB /SLIDE M311405-1 2 AB B
N
31 6927 5730 SWITCH ASSY / POWER M341019*1 1 BN B
Stand
N
32 6927 5680 PEDAL-BOX M241018*1 1 CX B
N
33 1004 3475 SCREW SET -415MM M341366C-1 1 BL B
AC cord
34 3701 1142 AC cord 5-989660 1 AZ C 120V, USA
34 3701 0595 AC cord EC-654-E06 1 BP C 230V, Europe
240V, Other countries
34 3701 1008 AC cord SP22-17022A 1 CD C 230V, UK
Notes: N- New parts
Q-Quantity used per unit
R-Rank
- 18 -
