N Item Code No. Parts Name Specification Q N.R.Yen R
Unit Price
Main PCB JCM719-MA1M
N 1 6923 4040 PCB ass'y JCM719-MA1M M140127*1 1 B
LSI101 2011 3325 LSI UPD6376CX 1 A
N LSI102 2012 0021 LSI HD6433298A36P 1 A
N LSI103 2012 0035 LSI TC5316200CP-C106 1 A
LSI105 2011 7434 LSI HG51B155FD 1 A
LSI106 2011 5194 LSI HG52E35P 1 A
N LSI107 2012 0028 LSI SRM2264LC90,10 2 A
IC101 2105 2114 IC, Regulator S-81350HG 1 A
IC102 2114 2891 IC LA4598 1 A
IC103 2114 1421 IC, Photocoupler PC900V 1 A
N IC104 2105 3941 IC RE5VA35AA-TZ 1 A
IC105 2114 1799 IC M5218APR 1 A
IC106 2105 2912 IC HD74HC08P 1 A
IC107 2105 3136 IC HD74HC00P 1 A
Q101 2251 0665 Transistor 2SB1240R.S-TV6-T 1 A
Q102, Q104, 2252 0896 Transistor 2SC1740S-R,S-TP-T
6
A
Q107/108,
Q121/122
Q103 2251 0651 Transistor 2SB1274-CCC 1 A
Q105 2253 0455 Transistor 2SD1762E,F 1 A
Q106 2250 0574 Transistor 2SA933SQ,R-TP-T 1 A
Q109~116 2259 1883 Digital transistor DTA114TS-TP-T 8 A
D101 2360 2233 Zener diode RD5.1JSB1-T1-T 1 A
D102 2360 0098 Zener diode RD5.1ESB2-T1-T 1 A
D103 2390 0371 Diode DSK10B-BT-T 1 B
D104 2390 1316 Diode SB10-04A3-BT-T 1 B
D105/106, 2390 1344 Diode 1SS133T-77-T
5
B
D108,
D111/112
D107 2310 7996 Zener diode RD4.7ESB2-T1-T 1 A
D109 2390 1995 Diode RB441Q-T77-T 1 B
X101 2590 1526 Ceramic oscillator EFO-EN2005C4 1 B
X102 2590 1519 Crystal oscillator HC-49U16384 1 B
MC101 2819 5552 Module Capacitor CNB7X102M 1 C
MC102 2845 0168 Module Capacitor CNB8X101K 1 C
FB102~114 2845 3220 Ferrite beads EXC-ELDR35V-T 13 C
EF101~103 3025 0826 EMI filter EXC-EMT222DT-T 3 C
J101 3501 7049 DC jack HEC2305-01-330 1 A
J102 3612 0665 Phone jack YKB21-5006 1 B
J103 3612 0789 Jack YKB21-5010 1 B
J104 3501 4816 DIN jack YKF51-5051 1 B
L101~104, 3841 0539 Inductor ELE-V100KR-T
10
C
L106~111
N L121 3841 1456 Coil CM08RB01 1 C
N
4317 5522 Blank PCB JCM719-MA1M M140129B-1
1
Volume PCB JCM719-MA2M
2 6923 4050 PCB ass'y M719-MA2M M440151*1 1 B
VR101 2765 1575 Slide volume EWA-MJ0S10B23 1
A
2-1 3719 2562 Ribbon cable M296D DF5H05130-MM
1C
N 4317 5532 Blank PCB JCM719-MA2M M140129B-2 1 C
Console PCB JCM719-CN1M
N 3 6923 4060 PCB ass'y M719-CN1M M140128*1 1 B
IC303/304 2105 3045 IC HD74HC174P 2 A
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
— 21 —
