Casio AT-1 User Manual

FOB Japan
N Item Code No. Parts Name Specification Q N.R.Yen R
Unit Price
IC301/302 2114 3318 IC BA612 2 A
LED301~309, 2370 0343 LED LN28RPX-(TT)
9
C
LED311
LED309/310 2370 0959 LED LN882RPX-(TT) 2 C
N LED312 2370 1141 LED SL-9352-60 1 C
D301~368 2390 1344 Diode 1SS133T-77-T 68 C
3-1 3719 4235 Ribbon cable M711C DF5H12120-MM 3 C
N 4317 5540 Blank PCB JCM719-CN1M M140130-1 1 C
LED PCB JCM719-CN2M
N 4 6923 4070 PCB ass'y M719-CN2M M340168*1 1 B
N 2370 1148 LED LN28RPH(V)-(TA9) 27 C
N 4317 5550 Blank PCB JCM719-CN2M M140130-2 1 C
Keyboard PCBs
N 5 6923 6940 PCB ass'y M617T-KY1M M140211*1 1 B
2301 0101 Diode 1S2473-T-77-T 64 C
N 5-1 3719 4557 Ribbon cable DF5H16200-MM 1 C
N 4317 5560 Blank PCB M617T-KY1M M140200-1 1 C
N 6 6923 6950 PCB ass'y M617T-KY2M M140212*1 1 B
2301 0101 Diode 1S2473-T-77-T 58 C
N 6-1 3719 4564
Ribbon cable DF5H17200-MM
1C
N 4317 5570 Blank PCB M617T-KY2M M140201-1 1 C
Bender
2765 1141 Volume RK1631110-50KB 1 C
Mechanical Parts
N
7 6923 4250 Display plate 719 M340042-1 1
C
8 6921 5040 Slide knob M311860-1
1
B
N
9 6923 4290 Panel 719 M140037-1 1
C
10 3831 0357 Speaker 1221AF
2
B
11 6922 3830 Rubber button 711A M312122-1
1
B
12 6922 3840 Rubber button 711B M312123-1
1
B
N 13 6923 4300 Rubber button 711C M312124-2
1
B
N
14 6923 4310 Rubber button 711F M211727-2 1
B
N
15 6923 4320 Rubber button 711E M312126-2 1
B
16 6922 2680 Rubber button 710D M312082-2
1
B
17 6922 3870 Rubber button 711D M312125-1
2
B
18 6922 2660 Rubber button 710C M312088-1
1
B
N
19 6923 4350 Rubber button 719A M340038-1 1
B
N
20 6923 4360 Rubber button 719B M340039-1 1
B
21 6922 2840 White key set CEGB M111723-1
5
A
22 6922 2860 White key set DFAS M111725-1
1A
23 6922 2850 White key set DFA M111724-1
4A
24 6922 2740 Black key set 10P M111726-1
2A
25 6922 2750 Black key set 5P M111726-2
1A
N 26 6923 4410 Bender knob M340169-1 1 C
6911 5241 Bender chassis A M31487A-1 1 C
6911 5250 Bender chassis B M41946-1 1 C
6911 5260 Bender spring M41949-1 1 C
N 27 3719 4536 Ribbon cable M719F DF5H03095-35353535 1 C
N 28 6922 3925 Upper case sub ass'y M111732E*2 1 C
28-1 6902 6140 Battery spring 90 M41226-1 1 B
28-2 6903 2150 Battery spring B M41330-1 1 B
28-3 6922 2810 Lower key stopper 710 M412287-1 1 C
28-4 6922 2820 Upper key stopper 710 M412286-1 1 C
28-5 6922 4480 Key damper 710 M412324-1 1 C
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
— 22 —
