Casio AT-1 User Manual

— 23 —
FOB Japan
N Item Code No. Parts Name Specification Q N.R.Yen R
Unit Price
29 6922 2761 Key contact rubber LT-CB M211704A-1 4 A
30 6922 2771 Key contact rubber LT-CS M211705A-1 1 A
31 6922 2631 Bottom plate 710 M211706A-1 1 C
N 32 6918 1636 Battery cover M311164F*1 1 B
N 6923 4280 Rating plate M312163-2 1 C
Accessory
6920 8680 Dust cover 590 M311784-1 1 B
6920 8691 Music stand 590 M311760A-1 1 B
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
Description of Capacitors
A general description of capacitors is shown in the following table.
The description consists of Type, Value, Rated Voltage and Tolerance.
When you need a capacitor, please find a subsutitution in your country by yourselves referring to the
description.
Ref. No of Capacitor Description
C101, C107, C125, C211 Electrolytic, 16 V, 470 µF, +/-20%
C110, C153 Electrolytic, 6.3 V, 220 µF, +/-20%
C103, C104, C113, C114, C121, C137~C139, C145, C167, C171, C193,
C197
Electrolytic, 10 V, 22 µF, +/-20%
C108 Electrolytic, 16 V, 10 µF, +/-20%
C152, C162 Electrolytic, 50 V, 1 µF, +/-20%
C111, C182 Electrolytic, 6.3 V, 470 µF, +/-20%
C102, C124, C126, C134, C159~C161 Electrolytic, 6.3 V, 100 µF, +/-20%
C123, C127 Electrolytic, 10 V, 100 µF, +/-20%
C144, C165 Semiconductive, 16 V, 2200 pF, +/-10%
C147, C164 Semiconductive, 16 V, 0.033 µF, +/-10%
C130, C131 Semiconductive, 16 V, 0.047 µF, +/-10%
C128, C129, C154, C174 Semiconductive, 16 V, 0.01 µF, +/-10%
C118, C119 Semiconductive, 16 V, 0.018 µF, +/-10%
C140, C155, C166, C170, C175~C179, C181, C185, C186, C188, C189,
C192, C194~C196, C198, C200
Ceramic, 50 V, 0.1 µF, +80/-20%
C105, C120, C132, C133, C135, C136, C141, C142, C146~C150, C163,
C172, C173, C180, C184, C187, C212~C214
Ceramic, 50 V, 100 pF, +/-10%
C122, C199 Ceramic, 50 V, 1000 pF, +/-10%
C168 Ceramic, 50 V, 0.01 µF, +/-20%
C191 Semiconductive, 16 V, 33 pF, +/-10%
C156, C157 Semiconductive, 16 V, 4 pF, +/-0.5 pF
C190 Semiconductive, 16 V, 22 pF, +/-10%
C116, C117 Mylar, 50 V, 0.047 µF, +/-10%
C112, C115 Electrolytic, 10 V, 1000 µF, +/-20%
