Casio AT-5

Using the Tone Editor
E-48
DSP Parameters 1
through 8
Shows up to eight parameters for “DSP Type”.
*2 *2
DSP RevSend
(DSP Reverb Send)
Adjusts how much reverb is applied to the post-DSP note. 0 to 40
*
to 127
Mod Setting
(Modulation Setting)
Assigns either vibrato or DSP to the S-2 (MODULATION) button. Vib
*
, DSP
Mod Depth
(Modulation Depth)
When vibrato is assigned to the S-2 (MODULATION) button, specifies the
depth of vibrato applied to a tone while the button is depressed.
0 to 127 (Default
setting depends on
the tone.)
Mod Button Assign
*3
(Modulation Button
Assign)
Specifies the function assigned to the S-2 (MODULATION) button when “DSP”
is selected for the “Mod Setting”. Specifying a value from 1 through 8 assigns
the corresponding DSP parameter (1 through 8). Nothing is assigned to the
button when “oFF” is selected for this parameter.
oFF
*
, 1 to 8
*4
Mod Button On Value
*3
(Modulation Button On
Value)
Specifies how the function currently assigned to the S-2 (MODULATION)
button works while the button is depressed.
*5
Mod Button Off Value
*3
(Modulation Button Off
Value)
Specifies how the function currently assigned to the S-2 (MODULATION)
button works while the button is released.
*5
*1 See “Preset DSP List” (page E-150) for information about the DSP types of each preset DSP.
*2 The number of DSP parameters, their content, and their setting ranges depend on the DSP type. For details, see “DSP Type
List” (page E-151) and “DSP Parameter List” (page E-152).
*3 Included in the “Mod Button” group. To change the settings of these parameters, move the 0 to “Mod Button” and then press
the R-16 (ENTER) button. Next, use the R-17 (t, y) buttons to move the 0 to the parameter whose setting you want to
change.
*4 Setting range depends on the selected DSP type.
*5 Depends on the selected DSP type and the “Mod Button Assign” setting.
Parameter Name Description Setting Range
