— 10 —
RESET button
About the [Action] Control
Operations can be performed by pressing and rotating the [Action] control.
Pressing the [Action] control
performs an operation
similar to the Enter key of a
computer keyboard.
Rotating the [Action] control
performs operations similar to
the up and down arrow keys
of a computer keyboard.
See Pocket PC online help for information about using the [Action] control with each
application. The text in the online help indicates an [Action] control press operation
as “Action,” and an [Action] control rotate operation as “Up/Down control.”
Card lock switch
If the inserted card has
a lock, this switch locks
the card in place so it
does not come out
accidentally.
Main battery cover
Serial connector
For connection of the cradle,
the CASSIOPEIA USB
cable, or the RS-232C serial
cable.
Battery cover switch
Backup battery cover
