Casio Cassiopeia E-125 - Parts List

14. PARTS PRICE LIST
14-1.PCB ASSY, COMPONENTS and OTHERS
N Item Code No. Parts Name Specification Applicable Q Price Code R
PCB ASSY/MAIN (C141078*1)
1 6566 6260 SPRING/BATTERY C342892-1 Common 3 AA C
2 6566 3840 TAPE/SHIELD C443236-1 Common 1 AH C
3 6566 4660 TAPE C443536-1 Common 1 AA C
4 6566 4720 TAPE/INSULATION C443588-1 Common 1 AA C
5 6566 2100 SPACER C442708-1 Common 2 AA C
SW1 3412 1946 SWITCH EVQ7QH03W Common 1 AB C
SW2,SW3,S
W4
2370 1392 SWITCH EVQPSC02K Common 3 AB C
SW6 3412 2084 SWITCH SLLB12-A-B-B Common 1 AN C
SW200 3412 2107 SWITCH ABC1112P Common 1 AB C
CN3 3502 2568 CONNECTOR 52746-0690 Common 1 AB C
CN4 3502 2460 CONNECTOR 54104-4590 Common 1 AH C
N CN5 2259 2791 CONNECTOR 53916-0808 Common 1 AL C
CN205 2254 0553 CONNECTOR HEC3650-012010 Common 1 AG C
N CN306 3502 2647 JACK HSJ1494-01-010 Common 1 AF C
CN307 3502 2553 CONNECTOR 55350-5026 Common 1 AU C
CN308 3502 2644 CONNECTOR 52271-0490 Common 1 AA C
N CN309 3502 2296 CONNECTOR BM04B-SRSS-TB Common 1 AC C
N CN310 1003 4737 CONNECTOR 54393-4592 Common 1 AK C
Q1 2259 2695 TRANSISTOR DTA114YKAT146 Common 1 AA C
Q201,Q215,
Q222,Q226
2254 0490 FET 2SK1827-TE85L Common 4 AA C
Q207 7911 3038 TRANSISTOR/DIGITAL DTC114YUAT106 Common 1 AA C
Q300,Q301 2250 1605 TRANSISTOR 2SC4081T106 Common 2 AA C
Q304,Q306 2259 2513 TRANSISTOR/DIGITAL DTA114EUAT106 Common 2 AA C
Q305 2259 2765 TRANSISTOR/DIGITAL DTC114EUAT106 Common 1 AA C
D2 2370 1390 LED SML-210LTT86M Common 1 AA C
D201,D211 2360 3061 DIODE/SCHOTTKY RB491DT146 Common 2 AA C
D203,D204,
D205,D208
2895 3130 DIODE/SCHOTTKY RB051L-40TE25 Common 4 AC C
D207 7911 2114 DIODE RB751V-40TE-17 Common 1 AA C
D209,D210 7911 3787 DIODE M1FS4-4063 Common 2 AA C
D212,D215 2390 0623 DIODE/SCHOTTKY SB07-03C-TB Common 2 AC C
N X1 1002 8054 OSCILLATOR/CRYTAL FCX-03-45.1584M2 Common 1 AM C
N X2 1002 8055 OSCILLATOR/CRYTAL FCX-03-48.000M2 Common 1 AM C
N X3 1002 8045 OSCILLATOR/CRYTAL MC146-32.768K-7/20 Common 1 AK C
N X4 2590 2783 OSCILLATOR/CRYTAL FCX-03-18.432M2 Common 1 AL C
VR300 3122 3717 RESISTER/CHIP SEMI-FIXED MVR32HXBRN222 Common 1 AA C
IC203 2105 6328 IC/MOS XC62FP5002MR Common 1 AD C
IC204 2105 3773 IC/MOS TC7SH08FU-TE85L Common 1 AB C
IC205 2105 5824 IC/L-MOS TC7SH32FU-TE85L Common 1 AB C
INNER CASE ASSY
N 6 1003 6262 PCB ASSY/MAIN C141078*1 TK Common 1 EM B
7 1000 3145 PANEL/TOUCH KTB97B002A Common 1 BW B
8 1002 6477 LCD MODULE COM38T3104DPQ Common 1 EC B
9 6566 3690 CASE/INNER C140810-1 Common 1 AM X
10 6566 3700 PLATE C342313-1 Common 1 AE C
- 70 -
