Casio CASSIOPEIA EG-800 - Parts List

PARTS PRICE LIST
EG-800
N Item Code No. Parts Name Specification Q Price Code R
PCB ASSY/MAIN (C141081)
IC200 1001 1100 LSI BD6097KU 1 BU C
N IC700 1001 1087 IRDA MODULE TFDU6101E-TR3 1 BK C
D3 2370 1390
LED
SML-210LTT86M 1 AA C
N D218 1002 8050 LED SML-521MDWT86 1 AC C
VR300 3122 3717 RESISTER/CHIP SEMI-FIXED MVR32HXBRN222 1 AA C
SW1, SW2,
SW3
2370 1392 SWITCH EVQPSC02K 3 AB C
SW4 1001 1066 SWITCH SLLB31-B-B-B 1 AN C
N X1 1002 8054 OSCILLATOR/CRYSTAL FCX-03-45.1584M2 1 AM C
N X2 1002 8055 OSCILLATOR/CRYSTAL FCX-03-48.000M2 1 AM C
N X3 2590 2783 OSCILLATOR/CRYSTAL FCX-03-18.432M2 1 AL C
N X4 1002 8045 OSCILLATOR/CRYSTAL MC146-32.768K-7/20 1 AK C
CN1, CN8 1001 1097 CONNECTOR 52746-1490 2 AC C
N CN2 1002 5185 CONNECTOR 55565-5026 1 AV C
CN3 2259 2752 CONNECTOR TCX3110-010100 1 AR C
CN5 1001 1098 CONNECTOR 53748-0808 1 AO C
CN9 3502 2710 CONNECTOR 54393-5192 1 AL C
N CN10 1002 9926 CONNECTOR 52746-0890 1 AB C
CN11, CN6 3502 2568 CONNECTOR 52746-0690 2 AB C
CN209 1001 1094 CONNECTOR CCA-4014-1205H 1 AS C
1 1001 1055
PLATE 55518-0011 1 AN C
2 6566 3010 SPACER C443027-1 2 AA C
N 3 6562 1600 TERMINAL/LUG C442156-1 1 AA C
CN600 1001 1097 CONNECTOR 52746-1490 1 AC C
CN601 1002 8032 CONNECTOR HSJ1594-010010 1 AF C
CN602 1001 2339 CONNECTOR HEC3604-010110 1 AE C
N 4 1002 9937 CABLE/JOINT C444443-1 1 AD C
PCB ASSY/KEY (C343497*1)
5 3335 6578 SPEAKER 20D2 1 AV C
6 1001 2019 TAPE/INSULATION C443896-1 1 AA C
7 1001 2020 SPACER C443899-1 1 AA C
8 1001 2021 BATTERY/LITHIUM VL2320/1F2 1 AV C
9 1001 5221 TAPE/INSULATION C444196-1 1 AA C
CN4 1001 1097 CONNECTOR 52746-1490 1 AC C
SW10 1002 1883 SWITCH SSSS812-B-2B 1 AB C
INNER CASE UNIT
10 1003 0001 LCD MODULE COM38T3106DPQ 1 EC B
11 1003 0002 INVERTER INV-J598-S 1 BR C
12 1002 9990 CASE/INNER C141059-1 1 AG X
13 1002 9992 CUSHION C444416-1 1 AA C
15 1002 9994 CUSHION C444418-1 1 AA C
16 1002 9995 CUSHION C444419-1 1 AB C
17 1002 9996 TAPE/ADHESIVE C444421-1 1 AA C
18 1002 9997 TAPE/ADHESIVE C444423-1 1 AA C
19 1002 9998 CABLE/JOINT C444441-1 1 AC C
20 1002 9999 SPRING/EARTH C444442-1 1 AA C
