Casio CDP-200R Service Manual & Parts List

– 13 –
1 CDP-200R_DI_120V
2 CDP-200R_DI_230V
3 CDP-200R_EU
4 CDP-200R_UI_UK
5 CDP-200R_US
1 2 3 4 5
Case unit
N 8 10310728 BL ASSY TK-RJM508735*001 1 1 1 1 1 C
9 10247802 REFRECTOR RJM506719-001V01 1 1 1 1 1 AG X
10 10255738 LED UY4067S-9B1 4 4 4 4 4 X
N 11 10308372 LCD TY11276N-A0158/08 1 1 1 1 1 C
12 10248658 CONNECTOR RJM506848-001V01 2 2 2 2 2 AJ X
13 10037738 SPONGE M441167-1 2 2 2 2 2 AA X
14 10244704 TOP PIECE RJM506943-001V01 2 2 2 2 2 AA X
15 10244703 FILM RJM506942-001V01 1 1 1 1 1 AA X
16 10244501 PLATE/BL RJM506777-001V01 1 1 1 1 1 AO X
N 17 10310735 COVER ASSY/SP/LEFT TK-RJM508736*001 1 1 1 1 1 X
N 18 10310736 COVER ASSY/SP/RIGHT TK-RJM508737*001 1 1 1 1 1 X
19 10284878 SPEAKER C0612J01 2 2 2 2 2 BO B
N 20 10308815 HARNESS EH-2P-15-M810 1 1 1 1 1 X L
N 21 69264590 SPONGE M440564-1 2 2 2 2 2 AA X L,R
N 22 10308814 HARNESS EH-2P-85-M810 1 1 1 1 1 X R
23 10216001 SPONGE RJM506430-001V01 1 1 1 1 1 AE X R
24 10269765 KNOB/RTR M341109-008V01 2 2 2 2 2 AD C
N 25 10306474 PLATE/DISPLAY RJM508552-001V01 1 1 1 1 1 C
N 26 10306479 RUBBER KEY/A RJM508560-001V01 1 1 1 1 1 AA C
N 27 10306480 RUBBER KEY/B RJM508561-001V01 1 1 1 1 1 AD C
N 28 10306481 RUBBER KEY/C RJM508562-001V01 1 1 1 1 1 AC C
N 29 10306482 RUBBER KEY/D RJM508563-001V01 1 1 1 1 1 AA C
N 30 10306483 RUBBER KEY/E RJM508564-001V01 1 1 1 1 1 AB C
N 31 10306484 RUBBER KEY/F RJM508565-001V01 1 1 1 1 1 AB C
N 32 10306485 RUBBER KEY/G RJM508566-001V01 1 1 1 1 1 AC C
N 33 10306486 RUBBER KEY/H RJM508567-001V01 1 1 1 1 1 AF C
N 34 10306487 RUBBER KEY/J RJM508568-001V01 1 1 1 1 1 AA C
N 35 10314505 PANEL ASSY TK-RJM505332*010 1 1 1 1 1 C
N 36 10306459 HOLDER/JACK RJM505667-002V01 1 1 1 1 1 X
N 37 10310738 PCB ASSY/JKA1 TK-RJM508897*001 1 1 1 1 1 C
J504 10210582 DC JACK HEC2305-016920 1 1 1 1 1 AC C
J501 10206815 CONNECTOR JY-6314*01-030 1 1 1 1 1 AA C
J502 10206816 CONNECTOR JY-6314*01-130 1 1 1 1 1 AA C
N J503 10305131 CONNECTOR ST-3529B 1 1 1 1 1 X
L502 10231919 COIL RB53-856396NP 1 1 1 1 1 AA X
L501,503 10231920 COIL RB53-856397NP 2 2 2 2 2 AA X
IC501 10211950 I.C NJM2068M-D(TE1) 1 1 1 1 1 AC X
N 38 10306472 SIDE CASE/IL RJM508550-001V01 1 1 1 1 1 C
N 39 10310726 BENDER ASSY TK-RJM504468*005 1 1 1 1 1 C
N 40 10306473 SIDE CASE/IR RJM508551-001V01 1 1 1 1 1 C
N 41 10306467 SIDE CASE/L RJM508548-001V01 1 1 1 1 1 C
N 42 10306470 SIDE CASE/R RJM508549-001V01 1 1 1 1 1 C
43 10203785 SCREW S-TRMA-6X30B3 4 4 4 4 4 AA C
N 44 10179177 HIMELON RJM505229-001V01 2 2 2 2 2 X
N 45 10209201 PACKING RJM506148-001V01 2 2 2 2 2 X
N 46 10214405 PACKING RJM506367-001V01 1 1 1 1 1 X
N 47 10305236 HIMELON M411136-003V03 1 1 1 1 1 X
N 48 10214401 PACKING RJM506159-001V01 1 1 1 1 1 X
49 69255770 HIMELON M440339-1 2 2 2 2 2 X
N 50 10219387 HIMELON RJM506468-001V01
5 5 5 5 5 X
N 51 10306463 SIDE BRACKET RJM508544-001V01 4 4 4 4 4 X
52 69265870 SPONGE M440591-1 1 1 1 1 1 AB X For FFC
N 53 10306477 HOLDER/SP/A RJM508556-001V01 1 1 1 1 1 X
N 54 10306478 HOLDER/SP/B RJM508557-001V01 1 1 1 1 1 X
RemarksSpecification
Q'TY
Price
Code
RN Item Parts NO. Parts Name

Casio CDP-200R Specifications

General

MIDI-keyboard number of keys	88 keys
Product color	Black
Pitch bend wheel	Yes
Interface	USB
Dimensions (WxDxH)	1333 x 278 x 133 mm
Power consumption (typical)	18 W

Weight and Dimensions

Weight	12000 g
