Casio CDP-200R Service Manual & Parts List

– 14 –
1 CDP-200R_DI_120V
2 CDP-200R_DI_230V
3 CDP-200R_EU
4 CDP-200R_UI_UK
5 CDP-200R_US
*1 : Three kinds of plugs(Euro, Austrailia, Korea) are bundled.
1 2 3 4 5
55 10175759 PACKING RJM504745-001V01 5 5 5 5 5 AA X
N 56 10175758 PACKING RJM504744-001V01 1 1 1 1 1 X
57 10209204 PACKING RJM506160-001V01 4 4 4 4 4 AA X
58 10216009 PACKING RJM506422-001V01 4 4 4 4 4 AA X
N 59 10209203 PACKING RJM506157-001V01 1 1 1 1 1 X
60 69321322 PACKING M441333-1 4 4 4 4 4 AA X
61 10268012 FERRITE CORE K5ARH16X9X17 1 1 1 1 1 AX C
N 62 69264590 SPONGE M440564-1 1 1 1 1 1 AA X
Key board assy
63 10294094 PCB ASSY/KEY/RUBBE
R
TK-RJM506061*003 1 1 1 1 1 CU C
N D801-D888 10294400 DIODE LM1MA142WKT1G 88 88 88 88 88 X
64 37195442 CABLE N30315B1B05-UL2896 1 1 1 1 1 AO C
65 10133656 RUBBER/CONATCT/AG RJM502920-001V01 7 7 7 7 7 AK B
66 10133635 RUBBER/CONATCT/GC RJM502921-001V01 1 1 1 1 1 AG B
67 10135317 BLACK KEY RJM502797-001V01 36 36 36 36 36 AC C
68 10135426 WHITE KEY/CEGB RJM502862-001V01 7 7 7 7 7 AT C
69 10135427 WHITE KEY/DFA RJM502863-001V01 7 7 7 7 7 AQ C
70 10135428 WHITE KEY/B RJM502794-001V01 1 1 1 1 1 AG C
71 10135429 WHITE KEY/SA RJM502795-001V01 1 1 1 1 1 AJ C
72 10135430 WHITE KEY/SC RJM502796-001V01 1 1 1 1 1 AJ C
73 10208265 HAMMER ASSY/W1 TK-RJM506035*001 13 13 13 13 13 AF C
74 10208266 HAMMER ASSY/W2 TK-RJM506036*001 13 13 13 13 13 AF C
75 10208267 HAMMER ASSY/W3 TK-RJM506037*001 13 13 13 13 13 AF C
76 10208269 HAMMER ASSY/W4 TK-RJM506038*001 13 13 13 13 13 AF C
77 10208275 HAMMER ASSY/B1 TK-RJM506039*001 9 9 9 9 9 AE C
78 10208281 HAMMER ASSY/B2 TK-RJM506040*001 9 9 9 9 9 AE C
79 10208286 HAMMER ASSY/B3 TK-RJM506041*001 9 9 9 9 9 BJ C
80 10208290 HAMMER ASSY/B4 TK-RJM506042*001 9 9 9 9 9 AE C
N 81 10310740 CHASSIS ASSY TK-RJM506053*007 1 1 1 1 1 C
N 82 10311215 CUSHION/HAMMER RJM509043-001V01 1 1 1 1 1 BI C
N 83 10310741 CASE ASSY/LOWER TK-RJM505967*005 1 1 1 1 1 C
N 84 10314506 KEY ASSY TK-RJM506464*007 1 1 1 1 1 A
ACCESSORY
- 10133504 PEDAL ASSY TK-RJM503195*001 1 1 1 1 1 BN C
- 10303050 AC ADAPTOR AD-12ML(E)-FC1(D) 1 DE C For UK
- 10303048 AC ADAPTOR AD-12ML(U)-FC1(D) 1 1 CW C For US
- 10303049 AC ADAPTOR AD-12MLGKA-FC1(D) 1 1 DE C
*1
N - 10306488 STAND/MUSIC RJM508666-001V01 1 1 1 1 1 C
N Item Parts NO. Parts Name Specification
Q'TY
Price
Code
R Remarks

Casio CDP-200R Specifications

General

MIDI-keyboard number of keys	88 keys
Product color	Black
Pitch bend wheel	Yes
Interface	USB
Dimensions (WxDxH)	1333 x 278 x 133 mm
Power consumption (typical)	18 W

Weight and Dimensions

Weight	12000 g
