- 21 -
2) Print aging test (R/J printer)
This test will check the R/J printer continuously until pressing some key button or turn off
the mode switch.
Operation : n1 Y X 2 #2 Key
X: 0= Print 45 times test pattern without paper cut in a minute.
1= Print 15 times test pattern with paper cut in a minute.
Y: 0= Normal print
1= Continuously print
n1: 0= Display test pattern
1= All segment will light on.
[PRINT] [DISPLAY]
Segment display (Test pattern)
3) Print test (R/J printer)
This test will check the R/J printer. To stop the continuous printing, press some key
button or turn off the mode switch.
Operation : n1 n 0 X 0 #2 Key
X: 0= One time print
1= Continuously print
n: 0= Display test pattern
1= All segment will light on.
n1: 0= Print test pattern
1= Print all "B"
[PRINT] [DISPLAY]
Segment display (Test pattern)
Print all "B"
Print test pattern
