Casio CE-6000 Service Manual

N Item CodeNo. Partsname Specification Q'ty Pricecode R
USA Canada
R23 RESISTOR/CHIP RC1608-563-F-T 1 1 X
RESISTOR/CHIP RC1608-472-F-T 2 2 X
R26 RESISTOR/CHIP RC1608-104-J-T 1 1 X
R27 RESISTOR/CHIP MCR03EZHF3600 1 1 X
R28 RESISTOR/CHIP MCR03EZHF1540 1 1 X
R3 RESISTOR/CHIP MCR50JZHJ202 1 1 X
R32 RESISTOR/CHIP RC1608-334-J-T 1 1 X
R33 RESISTOR/CHIP RC1608-105-J-T 1 1 X
R38 RESISTOR/CHIP RC1608-432-F-T 1 1 X
R39 RESISTOR/CHIP RC1608-622-F-T 1 1 X
RESISTOR/CHIP RC1608-103-J-T 13 13 X
R40 RESISTOR/CHIP RC1608-123-F-T 1 1 X
RESISTOR/CHIP RC1608-101-J-T 2 2 X
R59 RESISTOR/CHIP RC1608-822-J-T 1 1 X
R6 RESISTOR/CHIP RC1608-202-J-T 1 1 X
RESISTOR/CHIP RC1608-563-J-T 2 2 X
R7 RESISTOR/CHIP RC1608-623-J-T 1 1 X
R70 RESISTOR/CHIP MCR18EZHJ102 1 1 X
RESISTOR/CHIP RC1608-331-J-T 5 5 X
R8 RESISTOR/CHIP RC1608-332-J-T 1 1 X
R9 RESISTOR/CHIP MCR50JZHJ222 1 1 X
2.MaindisplayPCBblock
2 61935012 PCBASSY/E445A-E2 E340792*1 1 1 DC B
N IC1-3 21120823 IC/MOS BA12003BF-E2 3 3 AF A
IC4 10003984 IC/MOS SN74LV00APWR 1 1 AB A
10003982 IC/MOS SN74LV165APWR 3 3 AE A
IC7-9 20061703 LSI LC7932M-TE-R 3 3 AP A
LED1-10 24088398 LED GL8EG42 10 10 AA B
LED11-15 23201365 LED HDSP-5621#S02 5 5 AP B
Q1-5 22501603 TRANSISTOR 2SB1182TLQR 5 5 AC B
N CA1-6 28073624 CAPACITOR/MODULE MNA145A101KK 6 6 AA C
CN1 35405185 CONNECTOR HFW12S-2STE1 1 1 AB C
CN2 35405184 CONNECTOR HFW10S-2STE1 1 1 AB C
CN3 35017728 CONNECTOR B14B-PHDSS 1 1 AB C
CN4 35405190 CONNECTOR SFW27R-5STE1 1 1 AE C
CN5 35405196 CONNECTOR HFW9R-1STE1 1 1 AB C
CN6 35405186 CONNECTOR HFW24R-1STE1 1 1 AD C
FB1-30 30450028 INDUCTOR BK1608HS601-T 30 30 AA C
N RA1-9 26523056 RESISTOR/CHIPNETWORK MNR34J5ABJ121 9 9 AA C
N 26601174 RESISTOR/CHIPNETWORK RAC1608-3314DJT 4 4 AA C
N 26601156 RESISTOR/CHIPNETWORK RAC1608-1034DJT 6 6 AA C
N 27975519 RESISTOR/CHIPNETWORK RAC1608-1024DJT 7 7 AA C
N 27975518 RESISTOR/CHIPNETWORK RAC1608-1014DJT 3 3 AA C
C1-7 CAPACITOR/CHIP TMK107F104ZZ-T 7 7 X
C8-10 CAPACITOR/CHIP UMK107CH101JZ-T 3 3 X
RESISTOR/CHIP RC1608-471-J-T 5 5 X
RESISTOR/CHIP RC1608-121-J-T 2 2 X
R13 RESISTOR/CHIP RC1608-563-J-T 1 1 X
RESISTOR/CHIP RC1608-331-J-T 2 2 X
RESISTOR/CHIP RC1608-103-J-T 7 7 X
N 62481456 HOLDER/LED E340718-1 1 1 AF C
3.Customerdisplayblock
N 3 43081401 PCB/E445A-E2-2 E340800-1 1 1 AF X
4 23201365 LED HDSP-5621#S02 4 4 AP B
5 24088398 LED GL8EG42 2 2 AA B
N 6 35405193 CONNECTOR HLW10R-2C7 1 1 AB C
N 7 35405194 CONNECTOR HLW12R-2C7 1 1 AB C
N 62481566 HOLDER/LED E440663-1 1 1 AA C
WIRE/J UJW-C(10mm) 5 5 X
WIRE/J UJW-D(12.5mm) 3 3 X
WIRE/J UJW-E(15mm) 3 3 X
WIRE/J UJW-J(25mm) 1 1 X
8 62481475 CABLE/FFCJOINTDE445 E440657-4 1 1 AU C
9 62481476 CABLE/FFCJOINTEE445 E440657-5 1 1 AU C
10 62481785 CASE/REARDISPLAY E240511A-1 1 1 AH C
11 62481679 PLATE/REARDISPLAY E240512-3 1 1 AH B
N 62481698 PLATE/INSULATION E440781-1 1 1 AB C
4.Buttonblock
N 62481664 BUTTONSUBASSY E140293*2 1 1 EC X
12 62213988 CAP/L E210964-1 14 14 AB B
13 62214346 CAP/LLL E211131-1 1 1 AC B
- 60 -
